Protocol converter EM-483

Code of product:
NTEM48300
In stock
€185
5 years: product warranties
The device has been tested for operability
Quality confirmed by EU certificates

More Information

Dimensions, mm 1 DIN (18 mm)
Installation method Into a panel (DIN rail)
Інтерфейси зв'язку RS-485, Ethernet
Brand Novatek
Rated operating voltage, V 12 DC, 24 DC
Гальванічна розв'язка RS-485 Yes
Indication No, Web interface
Available delivery methods: Pickup from the store, Nova Poshta.
Payment methods: Bank transfer, Cash on delivery.
Technical documentation General description of the equipment, instructions, etc.

Detail product Description

The product is designed for data exchange over the 10BASE-T and 100BASE-T Ethernet network with equipment equipped with the RS-485 interface, which is made up of the MODBUS network.

EM-483 provides MODBUS server functions for MODBUS client connections over an Ethernet network. The product redirects MODBUS requests from customers to devices on the MODBUS network and returns responses from devices to customers

EM-483 provides:

  • flexible addressing in the Ethernet network (redefined MAC address, static or dynamic IP address)
  • protection of access through the Ethernet network (setting mode password, IP address filter for setting or for connecting to the MODBUS network)
  • different modes of exchange over the MODBUS network (RTU or ASCII, with Chet parity check, odd and without check, wide range of transmission speeds, adjustable delay)
